Datalogic Matrix 300N Fixed industrial scanner

Information:

Matrix 300N is an ultra compact image-based barcode reader designed for high-speed and direct part identification (DPM).

The Matrix 300N combines high-resolution sensors with ultra fast image acquisition capabilities, with up to 1.3 megapixels and a frame rate of 60 frames per second. The optical system adopts a liquid lens module, which realizes electronic control of focusing and can automatically adjust the focus without moving parts.

This model of reader adopts innovative lighting design, with integrated lighting fixtures embedded throughout the entire front surface. The lighting fixture has two lighting modes, bright field and dark field, which can provide perfect illumination for barcodes on ordinary, etched, highly reflective, or textured surfaces. The Matrix 300N ™ has an ultra compact shape and swivel joint, making it highly suitable for small spaces.

In addition, the M12, 4-core connector provides a new standard for the OEM industry to easily integrate into existing systems.

The Power over Ethernet (POE) option is a unique cost-effective feature that enables reader power and communication through a standard single Ethernet connection.

Matrix 300N is powered by the new software DL CODE driven, providing customers with maximum convenience in use.

Features/Advantages:

High performance DPM reading

Ultra compact reader, rotary connector system

Fast and high-resolution image sensor: 1.3 million pixels, "real" 60 frames per second

Optional Power over Ethernet

Integrated dual lighting: dark field/bright field
